| Mechanical Engineering Department |
| |
Laboratories & Major Equipment/Software
Sr. No |
Laboratory |
Facilities |
-
|
FMS Laboratory |
- 3D Metal Printer (ProX DMP 200)
- 3D Polymer Printer (uPrint FDM)
- 3D Bio-Printer (Allevi)
- 3D Scanner (Steinbichler COMET)
- Flexible Manufacturing System
- CNC Milling & Turning Simulator
- CAD Workstations – 31
- HP DesignJet T1200 Plotter
- Software – SolidWorks, Autodesk Inventor, MDT, CATIA, IDEAS, Delmia, MasterCAM, SolidCAM, ADSTEFAN,Creo, Flexsim, Simufact, Kissoft
|
-
|
Measurements & Metrology |
- Setup for condition monitoring system of gears, shafts and bearing
- Bearing Condition Monitoring Test Rig
- Vibration Analyzer and Accessories
- Thermal Imaging Camera
- Machine Vision & Inspection System
- Eddy Current Flaw Detector
- Magnetic Particle Crack Detector
- Basic Measuring Instruments
|
-
|
Machine Tool |
- CNC Vertical Milling Machine
- Piezo Electric 6-Component Dynamometer with accessories
- Condition Monitoring System Test and Measurement Equipment
- Cryogenic Treatment Equipment
- Spark Erosion EDM
- Electro Chemical Machine
- Lathes; Shaper; Milling Machine; Vertical drill machine
- Surface Grinder; Tool and Cutter Grinder
- Tungsten Inert Gas (TIG) Welding set
- Metal Inert Gas (MIG) Welding set
|
-
|
Material and Material Testing |
- Scanning Electron Microscope
- Spectrometer
- Potentiostat/galvanostat
- Universal Testing Machine – 01
- Digital Rockwell cum Brinell hardness tester
- Microhardness tester – 01;
- Ultrasonic Flaw Detector
- Wear Test Rig – 01
- Scratch tester
- Tool maker microscope
|
-
|
Mechatronics |
- Electro-Hydraulic Trainer Kit
- PLC controlled Electro-Pneumatic Kit with Ladder Diagram software
- Electronically Controlled X-Y Table, Conveyer and Rotary Table
- Microcontroller based DC Motor Control Trainer
- Robotic Manipulator with control and simulation software
- DSpace Data Acquisition Board
- Brushless DC Motor Control Trainer
- Stepper Motor Control Trainer
- Trainer Boards for Sensors (Strain Gauge, Ultrasonic, Thermocouple, Pressuere, Gas sensor etc.)
- Sensors / Transducers for measuring Pressure, Torque, Flow Rate, Position etc.
- Accessories - Oscilloscope, DC Power Supply, Function Generator etc.
- Software - Automation Studio, MATLAB with toolboxes, Mathematica
|
-
|
SCoE |
- Digital Twin Setup
- Smart Robot Manipulator
- Educational Robot Manipulator
- Turtlebot
- HP Z Workstations - 2
- HP Z840 Workstations - 4
- Software – ANSYS, COMSOL, Altair
|
 3DScanner |
 CNCSimulator |
 CryogenicTreatmentSetup |
 ScanningElectronMicroscope |
 FlexibleManufacturingSystem |
 ElectroChemicalMachine |
 3DMetalPrinter |
|
|
|
